1325 HEAWY STONE ENGRAVING MACHINE
| Working desk size | 1300mm *2500mm *200mm | ||
| Stereo engraving dimensions | 300mm high in diameter is 1800mm | ||
| Repeatability | <0.05mm/1000mm | ||
| Design/ Dragon Gate | Aluminum plate T-slot countertop + PVC, Fanggang gantry | ||
| Bed frame | Thickened and widened square tube welding bed (with horseshoe) | ||
Run motor | Stepper motor (optional same server/hybrid servo) | ||
| Spindle power | Water-cooled power 2.2kw, 3.0kw, 5.5kW (optional) | ||
| Spindle speed | 6000-24000R/min | ||
| Operating Voltage | 220V50Hz/380V50Hz | ||
| Run command | G code, f/s command is com patible | ||
| Maximum space speed | 15M-Min | ||
| Transfer method | axis screw + square rail X-axis rack+ square rail Y-axis rack+ square rai (Y-axis dual motor) | ||
| Control System | NC studio/Richauto | ||
| Inverter | Southern Anhua inverter | ||
| Rail model | 20/25 square rail (optional) | ||
| Transmission system | Rail+ oblique rack | ||
| Z-axis transmission system | High precision ball screw | ||
| A fixed way | Clamp | ||
| Dimensions | Diferent length 3000mm wide 2600mm high 1600mm | ||
| Total weight | About 1000 kg | ||
| Body color | Black red / blue white | ||
